Super100

品牌：ROCK RANGER

型号：SUPER100

介绍：

从一开始我们就想创造一台适合新一代年轻乐手的、功能强大、从录音棚至大型摇滚现场、从布鲁斯到各类摇滚乃至现代融合音乐、能够胜任各种场合与不同音乐风格、有极高的音色可塑性但又有着不错性价比的量产型吉他音箱。因此我们花了大量的时间与精力去研究那些历史上最经典的音箱和音色，反复地聆听与对比，并对每一个对音色有重要影响的元器件进行了深入的探索，最后，Super100诞生了！

Super100拥有CLEAN和DRIVE两个通道，具备独立的三段EQ调节、总临场度与低频深度控制、效果回路以及弹簧混响，还可以通过脚控或开关设置第一和第二通道的串联工作模式、两个独立的总音量控制，允许用户单独设定两个不同音量值以用于不同的应用，例如一个总音量为节奏，另一个为主音。

CLEAN通道带来饱满、圆润的音色质感，高频纯净且低频紧致，可以作为优秀的效果器平台。同时，如果将CLEAN通道的LEVEL开到十二点之后，就可以逐渐得到一种甜美的后级饱和过载的音色；即使是开到最大，也可以通过跟MASTER VOLUME的配合，制造出类似早期FENDER BASSMAN的过载音色。BRIGHT开关，能最大限度地适应你的吉他优化你的清音音色。而另一个fat开关则可以制造出肥厚的低中频与增加一定的增益度，带来了令人惊异的延音，当LEVEL开到两点钟左右的时候，非常容易得到华丽的清音FEEDBACK。通过控制吉他上的音量电位器可以做出非常类似f孔空心或半空心之类的吉他那种从浓厚清音到丝滑过载的演奏效果，fat功能也能直接给与一些出力不大的吉他甚至过载单块增加一定声音的厚度与力度。

DRIVE通道具有gain1和gain2两个过载模式，可单独调节各自的增益和音量，并可以通过面板上的开关或脚控进行切换。gain1的声音有点像跨越了典型的70年代到90年代初期的英式风格，但又有着自己的独特的个性，可以光滑圆润，也可以干脆硬朗，即使增益开到最大，也依旧能保持优秀的清晰度和颗粒感；gain2则是有着更高的增益，更具有冲击性的现代之声，音色的风格更像是英式与美式的完美结合。DRIVE通道还带有一个mid shift开关，同时适用于gain1和 gain2两种模式，提供了更多的中频饱满度。所以我们通常把gain2模式理解为Super100的第三个通道。

Super100最好玩最有意思的部分，是第一通道和第二通道的串联，这也是我们最喜欢的创意与设计。当切换到过载通道时，通过面板开关或脚控可以选择开启1+2工作模式，这时就变成了两个通道的串联工作，并同时适用于gain1 和gain 2。是的没错，清音通道串联过载通道，通过适当的调节与两个过载通道各自的功能组合，能创作出更多让你惊喜的声音，适用于更多不同的演奏需求与应用场合——比如你可以一脚切换经典的BROWN音色与标志性的德克萨斯之声，劲爆狂野的高增益现代金属之声与某一个全新的融合声音或优雅华丽的摩登蓝调音色等等；也可以通过调节，在不扰民小音量下的演奏仍然保持良好的动态与触感。但不仅只有这些，串联之后所带来的极其强大的可调性与无限可能性，将使你乐此不彼地沉浸其中去探索出属于自己独一无二的声音并享受它们。

我们期望SUPER100既像一位少年吉他英雄一般，英气迸发，我行我素，勇往直前；也如同一位久经沙场的老兵那样，浓厚醇香，回味无穷。

From the beginning, we wanted to create a mass-production guitar amplifier, which is suitable for new generation of young musicians, powerful, capable of various occasions from recording studios to large rock concert, from blues to all kinds of rock to modern fusion music and other different music styles, with high-quality sound malleable and good price-performance ratio. Therefore, we spent a lot of time and energy to study the most classic amplifiers and sounds in history, repeatedly listening and comparing, and in-depth exploration of each component that has an important influence on sound, and finally, Super100 was born !

Presence, low frequency depth control, effect loop and spring reverb.

Channel 1&2 in serial mode can be setup by switch on the panel or footswitch.

2 independent master volume controls allow user to set different volume for different applications, for example, one for rhythm and the other for solo.

The clean channel brings a full, rich tone, crystal clean high frequency and tight low frequency, which can be used as an excellent platform for effects. If you turn the LEVEL after 50%, you can get a sweet drive from the saturated power amp; even if the LEVEL is turned to 100%, you can also cooperate with the MASTER VOLUME, to create a sound like the early Fender bassman’ s drive tone. Independent bright switch can adapt your guitar tone and optimize your clean sound. The another FAT switch can bring you fat tight mid & low frequency, add gain, give you surprising sustain. When the LEVEL turns after 60%, you can easily get the beauiful feedback. The clean channel with FAT switch is very suitable to play guitars with f-hole hollow or semi-hollow, or it can increase the thickness and strength of the tone for the guitars with less output or even overdrive pedals.

The drive channel has two gain modes, gain1 and gain2, which can adjust the gain and master volume independently, and can be switched by the switch on panel or footswitch. The tone in gain1 is like the classic British style from the 70s to the early 90s, but it has its own unique personality, which can be smooth or tight; gain2 has higher gain and is more aggressive modern sound. The DRIVE channel also has a mid shift switch, which is applicable to both gain1 and gain2 modes, providing more mid frequence. So we can also regard gain2 mode as the third channel of SUPER100.

The most interesting part of super100 is the series connection of the clean channel and the drive channel: when switching to the drive channel, you can turn on the 1 + 2 mode through the panel switch or foot switch, then it becomes two channels working in series, which is applicable to both gain1 and gain 2. Yes, clean channel is connected in series with drive channel. Through proper adjustment and the combination of the functions of the two channels, you can create more surprising tone, suitable for more different needs and applications. For example, you can switching the classical Brown tone to the standard Texas sound, the wild high gain modern metal tone to some brand new and beautiful morden blues sound; it can also be adjusted to low volume, while still maintaining a good dynamic and touching fell. In addition, its powerful adjustability will make you immersed in it to explore the unique sounds and enjoy them.

We expect SUPER100 to be like a young guitar hero, bursting with courage and also like a veteran with lots of battlefield experience, rich, mellow and endless.

✪ 功率：100W

✪ 前级管：12AX7*5

✪ 后级管：6L6*4

✪ 通道数：3

✪ MASTER控制：MASTER VOLUME A/B，MASTER VOLUME A/B切换Switch，PRESENCE，DEPTH，REVERB

✪ Drive通道控制：第二通道LEVEL控制，第一通道LEVEL控制，TREBLE，MIDDLE，MID SHIFT中频提升SWITCH，BASS，第二通道GAIN控制，第一第二通道切换SWITCH，第一通道GAIN控制

✪ 通道控制：CLEAN通道与DRIVE通道串联SWITCH，通道切换SWITCH

✪ CLEAN通道控制：TREBLE，BRIGHT SWITCH，MIDDLE，BASS，FAT SWITCH，CLEAN通道LEVEL控制

✪ INPUT控制：HIGH/LOW切换SWITCH，输入插孔

✪ 喇叭输出：4Ω，8Ω，16Ω

✪ 带前级线路输出

✪ 效果回路
